M18 FUEL™ 1-9/16" SDS Max Rotary Hammer
M18 FUEL™ 1-9/16" SDS Max Rotary Hammer
2717-20
Product Description – Milwaukee 2717-20 M18 FUEL™ 1-9/16" SDS-Max Rotary Hammer
The Milwaukee 2717-20 is a M18 FUEL™ 18-volt cordless 1-9/16-inch SDS-Max rotary hammer engineered for heavy-duty drilling and chiseling in concrete and masonry. Powered by a POWERSTATE™ brushless motor, this tool delivers performance comparable to corded SDS-Max rotary hammers while providing the mobility of Milwaukee’s M18 battery platform.
Designed for demanding construction tasks, the rotary hammer produces up to 5.0 ft-lbs of impact energy, allowing fast drilling and efficient chipping in reinforced concrete and masonry materials. It operates at speeds up to 450 RPM with an impact rate of 3,000 BPM, providing the power needed for large anchor holes and demolition work.
The tool features 3 operating modes—rotary hammer, hammer-only, and rotation-only, making it suitable for drilling, chiseling, and light demolition tasks. Integrated REDLINK PLUS™ Intelligence protects the tool and battery from overload, overheating, and over-discharge for reliable job-site performance.
Key Features
- Brand: Milwaukee
- Part Number: 2717-20
- Product Type: Cordless rotary hammer (tool only)
- Voltage: 18V (M18™ battery system)
- Chuck Type: 1-9/16" SDS-Max
- Motor: POWERSTATE™ brushless motor
- Impact Energy: Up to 5.0 ft-lbs
- Speed: Up to 450 RPM
- Impact Rate: Up to 3,000 BPM
- Modes: Rotary hammer, hammer-only, rotation-only
- Technology: REDLINK PLUS™ electronic protection
- Battery/Charger: Sold separately
Typical Applications
- Drilling large anchor holes in concrete
- Concrete and masonry drilling
- Medium-duty demolition and chiseling
- Electrical and mechanical installations
- Commercial construction and renovation
