High Head Flow-Mate 160 - Seal Submersible Effluent Pump
High Head Flow-Mate 160 - Seal Submersible Effluent Pump
161-0002
How you'll get this item:
Stores Are Selected During Checkout.
COMPLEMENTARY PRODUCTS
MORE PRODUCT INFORMATION
FEATURES
FEATURES
• Oil-filled motor and cast iron motor housing for optimal heat dissipation which prevents the pump from overheating
• Nonautomatic operation that will require a piggyback float switch or control panel to control the pump's on / off level
• Corrosion resistant cast iron vortex impeller to allow free passage of 3/4 in spherical solids which prevents clogging and increases reliability
• Stainless steel screws, handle, and hardware to prevent rust and corrosion
• Powder-coated epoxy finish provides corrosion-resistance and extends the life of the pump in harsh environments
• 100% Factory Tested - every pump is submerged in water and tested at the factory to ensure that it performs as expected when you receive it
DIMENSIONS
DIMENSIONS
|
WIDTH |
12.75 in |
|---|---|
|
HEIGHT |
19.31 in |
|
WEIGHT |
82 lb |
PRODUCT OVERVIEW
The 1/2 HP Model N161 nonautomatic Effluent Pump is designed to remove grey water or effluent from effluent lift station or elevator vault applications. This corrosion resistant pump will provide the dependability expected from a Zoeller pump. Backed by a 1-year warranty, every pump is submerged in water and tested to its published performance curve, ensuring it meets your expectations and delivers peace of mind right-out-of-the-box.
SPECIFICATIONS
|
Amperage Rating |
15.5 A |
|---|---|
|
Automatic/Non Automatic |
Non-Automatic |
|
Bearing Type |
Ball |
|
Cord Type |
3-Wire Neoprene |
|
Dimensions |
12-3/4 in W x 19-5/16 in H |
|
Frequency Rating |
60 Hz |
|
Horsepower |
1/2 hp |
|
Impeller Type |
Bronze Non-Clogging Vortex |
|
Material |
Cast Iron |
|
Maximum Flow Rate |
100 gpm |
|
Maximum Head |
56 ft |
|
Motor Speed |
3450 rpm |
|
Outlet Size |
1-1/2 in NPT |
|
Phase |
1 |
|
Series |
High Head Flow-Mate 160 |

$1,122.68
