Loaded Clamp Meter - ABS - 400 A
Loaded Clamp Meter - ABS - 400 A
SC640
How you'll get this item:
Stores Are Selected During Checkout.
COMPLEMENTARY PRODUCTS
MORE PRODUCT INFORMATION
FEATURES
FEATURES
• Swivel-head with LED jaw flashlight
• Selector dial backlight
• Large backlit display
• Magnetic strap
• Lead storage
• Inrush current
• Swivel clamp
• Probe storage
• Frequency via leads and clamp
• Non-contact voltage alert
DIMENSIONS
DIMENSIONS
|
WIDTH |
79.5 mm |
|---|---|
|
HEIGHT |
287.5 mm |
DOCUMENTS & RESOURCES
PRODUCT OVERVIEW
The SC640 clamp meter is packed with more features and measurements than any clamp meter in the HVACR industry. The loaded SC640 features lead storage, a swivel head, test lead holder, heavy duty magnetic strap, jaw flashlight, and a backlight on the dial so you can easily choose the right measurement in poorly lit spaces. Plus the SC640 hosts all the electrical measurements HVACR pros use everyday, along with features like True RMS, Inrush current, capacitance, temperature, duty cycle, and uA DC.
SPECIFICATIONS
|
AC Response |
100 ms |
|---|---|
|
Counts |
5000 |
|
Dimensions |
287.5 mm H x 79.5 mm W x 50 mm D |
|
Display Type |
LCD |
|
Electrical Ratings |
400 A |
|
Frequency Rating |
50 to 500 Hz |
|
Material |
ABS |
|
Operating Temperature |
32 to 122 deg F |
|
Power Source |
Alkaline Battery |
|
Resistance |
50 MOhm |
|
Safety Rating |
600 V |

$289.18
