WOODFORD

Model 74 - 3/4" Anti-Siphon Close Coupled Wall Hydrant

Model 74 - 3/4" Anti-Siphon Close Coupled Wall Hydrant

74P-BR

$265.28
$265.28 $300.85
Shipping calculated at checkout.

How you'll get this item:

  • Ach Direct Debit
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

MORE PRODUCT INFORMATION

FEATURES

• Permanent type brass valve body with hemispherical seating surface
• No lead solder on all solder joints
• Hardened stainless steel stem resists damage
• EPDM rubber with adjustable packing nut
• Loose key operates hydrant

DIMENSIONS

WIDTH

5.5 in

HEIGHT

3.25 in

WEIGHT

3.2 lb

WARRANTY

5 Years Limited

DOCUMENTS & RESOURCES

Specification Sheet
Product Brochure

PRODUCT OVERVIEW

The Model 74, B74, and RB74 are anti-siphon protected wall hydrants designed for irrigation purposes in mild climate areas or within temperature controlled malls and plazas.

SPECIFICATIONS

Dimensions

5-1/2 in W x 3-5/8 in D x 3-1/4 in H

Domestic/Import

Domestic

End Style

FNPT

Handle Type

Tee Key

Nominal Size

3/4 in

Pressure Rating

125 psi

Series

Model 74

Temperature Rating

120 deg F

Type

Anti-Siphon Close Coupled
