Platinum - Dual Voltage Vacuum Pump with Us Plug - 5 CFM
Platinum - Dual Voltage Vacuum Pump with Us Plug - 5 CFM
DV-142N-250
How you'll get this item:
Stores Are Selected During Checkout.
COMPLEMENTARY PRODUCTS
MORE PRODUCT INFORMATION
FEATURES
FEATURES
• 1/2 hp, 1725/1425 rpm capacitor start motor with thermal overload protection
• 1/2 x 1/4 x 3/8 in intake port
• Standard US 220 V plug
• Gas ballast increases and keeps oil cleaner
• 2 stage direct drive to achieve deep 15 micron vacuum
• Check valve prevents oil back flow during power failure
• Low profile rocker switch
• Lift ring to hoist
• Tethered safety cap prevents oil spills during transport
• 1/2 in NPT break resistant handle encompasses exhaust
DIMENSIONS
DIMENSIONS
|
WEIGHT |
33 lb |
|---|
PRODUCT OVERVIEW
JB Industries PLANTINUM® series vacuum pump is the best pump in the industry. Designed for the serious air conditioning and refrigeration technician, the PLATINUM® vacuum pump features a gas ballast and blank off valve. American made and subjected to JBs rigorous performance standards, the PLATINUM® series is the top of the line for both quality and durability. Backed by an unprecedented 24 month over-the-counter warranty, there is no better pump on the market. Because each PLATINUM® pump is made at our factory in Aurora, Illinois, quality and dependability are woven in with hard working American pride. Completely field repairable, our PLATINUM® series is designed to last.
SPECIFICATIONS
|
Body Material |
Metal |
|---|---|
|
Displacement |
5 cfm |
|
Domestic/Import |
Domestic |
|
Frequency Rating |
50/60 Hz |
|
Horsepower |
1/2 hp |
|
Oil Capacity |
21 oz |
|
Series |
Platinum™ |
|
Type |
Dual Voltage |
|
Voltage Rating |
115/230 V AC |

$938.07
