Split System Air Conditioner Outdoor Unit - Wall Mount
Split System Air Conditioner Outdoor Unit - Wall Mount
AR09JSALBWKXCV
How you'll get this item:
Stores Are Selected During Checkout.
COMPLEMENTARY PRODUCTS
MORE PRODUCT INFORMATION
FEATURES
FEATURES
• Auto protection: With auto-protection, errors are displayed on the front LED, which helps with service and maintenance
• Timer mode: The Novus is equipped with a 24 hr/12 hr timer on/off
• LED display: Novus is equipped with a very user-friendly LED display
• Dehumidifier: This feature allows you to keep the room dry when it's humid outside
• Anti-cold air: In heating mode, the fan speed is controlled according to the evaporator temperature
• Only when the evaporator is warm enough will the fan begin to run, preventing cold air from being expelled
• 180 deg sine wave: True sine wave provides smooth, efficient operation, precise controls, and reduced noise levels
• Auto restart: when the Novus turns back on (after being turned off or after a power failure), all of the previous settings, including temperature, will be retained
• High efficient internal thread copper pipe: With the new trapezoidal internal thread copper pipe, the heat exchange area is increased, the heat exchange efficiency is improved and the heating efficiency is enhanced
• Quiet operation: Both the indoor and outdoor units are designed with quiet operation in mind
DIMENSIONS
DIMENSIONS
|
WIDTH |
29.81 in |
|---|---|
|
HEIGHT |
21.63 in |
|
WEIGHT |
66.1 lb |
WARRANTY
WARRANTY
7 Years Compressor, 5 Years Parts and 90 Days Limited Labor
PRODUCT OVERVIEW
SPECIFICATIONS
|
Control Type |
Electronic Expansion Valve |
|---|---|
|
Cooling Capacity |
12500 Btu/hr |
|
Dimensions |
29-13/16 in W x 10-1/16 in D x 21-5/8 in H |
|
Discharge Line Size |
3/8 in |
|
EER Rating |
13 |
|
Flow Rate |
1024 cfm |
|
Fuse Size |
25 A |
|
Heating Capacity |
13500 Btu/hr |
|
HSPF Rating |
9 |
|
Humidity Removal Capacity |
1.42 pts/hr |
|
Maximum Piping Length |
50 ft |
|
Motor Type |
Brushless DC |
|
Mounting Type |
Wall |
|
Nominal Capacity |
0.75 ton |
|
Power Source |
115 V AC, 1 ph, 60 Hz |
