T-1009NL - 1/2" Ball Valve - Brass

T-1009NL - 1/2" Ball Valve - Brass

101-643NL



Regular price $35.89
Sale price $35.89 Regular price $54.30
Shipping calculated at checkout.

How you'll get this item:

Payment methods
  • Ach Direct Debit
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

MORE PRODUCT INFORMATION

FEATURES

• Lead free chrome plated forged brass ball/end adaptor/body/stem, Dyneon® TFM® PTFE anti-friction thrust washer anti-friction washer/seat, dacromet coated steel handle dacromet coated steel with PVC resin lock handle nut, FKM fluoroelastomer stem O-Rings, forged brass compression nut, tubular brass ferrule
• Self-cleaning chrome plated ball resists mineral build-up and scaling typically found in harsh, varying water conditions
• Tubing compression connections permit easy, convenient, Lead free compliant replacement of a worn, leaded valve, without the need for sweating
• Quarter-turn, positive shutoff full port design, make the T-1009NL the ideal replacement for a leaking multi-turn, drip-tight, reduced port gate valve
• Bottom loaded blow-out proof stem
• Lead free design is suitable for all no lead potable water installations in full compliance of all Lead free plumbing laws
• Maintenance-free design
• TFM/PTFE thrust washer

DIMENSIONS

WEIGHT

0.52 lb

WARRANTY

5/25 Years

PRODUCT OVERVIEW


Legend offers more than 9,000 products representing 80 plus product classes designed for residential, commercial and industrial applications. Everything you many need for behind the wall, Legend has the most expansive offering of valves, fittings, tubing and components for plumbing and hydronic systems.


SPECIFICATIONS

Actuator Type

Quarter Turn Handle

Ball Material

Brass

Body Material

Brass

Domestic/Import

Import

End Style

C

Inlet to Outlet Length

2.96 in

Media

Oil/Water

Nominal Size

1/2 in

Port Type

Full

Pressure Rating

600 psi

Series

T-1009NL

Softgoods Material

TFM/PTFE

Top to Inlet Center

1.14 in

Trim Material

Brass Stem and PTFE Seat
