GRUNDFOS

Up Series - Canned Rotor Circulator Pump - 1 Phase

Up Series - Canned Rotor Circulator Pump - 1 Phase

UP1542B5

$428.52
$428.52 $772.00
Shipping calculated at checkout.

How you'll get this item:

  • Ach Direct Debit
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

MORE PRODUCT INFORMATION

FEATURES

• Ceramic shaft, radial bearings and carbon thrust bearing
• Stainless steel rotor can and bearing plate
• Impeller of corrosion-resistant material
• No additional motor protection is required
• Non-electronically controlled circulator pumps for domestic building with speed control
• Bronze pump housing
• Small stator
• 1-speed motor

DIMENSIONS

WIDTH

4.69 in

HEIGHT

5 in

WEIGHT

2.16 lb

DOCUMENTS & RESOURCES

Specification Sheet
User Manual
Product Brochure

PRODUCT OVERVIEW

The Grundfos circulator pumps, Series UP are specifically designed for heating systems. The pumps are also suitable for circulation of hot domestic water and for circulation of liquid in cooling and air conditioning systems.

SPECIFICATIONS

Amperage Rating

0.74 A

Bearing Type

Radial/Thrust

Dimensions

4-11/16 in W x 5 in H

Frequency Rating

60 Hz

Impeller Type

Composite PES

Inlet Size

1/2 in C

Maximum Head

15.09 ft

Maximum Pressure

145 psi

Outlet Size

1/2 in C

Phase

1

Power Rating

85 W

Series

UP Series

Temperature Rating

140 deg F

Type

Canned Rotor

Voltage Rating

115 V AC
