Up Series - Canned Rotor Circulator Pump - 2.75 GPM

Name: Up Series - Canned Rotor Circulator Pump - 2.75 GPM
Brand: GRUNDFOS
SKU: UP1510B5LC
Price: 443.39 USD
Availability: InStock

UP1510B5LC

$443.39

$443.39 ~~$461.00~~

Shipping calculated at checkout.

How you'll get this item:

MORE PRODUCT INFORMATION

FEATURES

• Ceramic shaft, radial bearings and carbon thrust bearing
• Stainless steel rotor can and bearing plate
• Impeller of corrosion-resistant material
• No additional motor protection is required
• Non-electronically controlled circulator pumps for domestic building with speed control
• Line cord
• Bronze pump housing
• Small stator
• 1-speed motor

DIMENSIONS

WIDTH	6.19 in
HEIGHT	5 in
WEIGHT	2.36 lb

DOCUMENTS & RESOURCES

Specification Sheet

User Manual

Product Brochure

PRODUCT OVERVIEW

The Grundfos circulator pumps, Series UP are specifically designed for heating systems. The pumps are also suitable for circulation of hot domestic water and for circulation of liquid in cooling and air conditioning systems.

SPECIFICATIONS

Amperage Rating	0.22 A
Bearing Type	Radial/Thrust
Dimensions	6-3/16 in W x 5 in H
Flow Rate	2.75 gpm
Frequency Rating	60 Hz
Impeller Type	Composite PES
Inlet Size	1/2 in C
Maximum Head	6.234 ft
Maximum Pressure	145 psi
Outlet Size	1/2 in C
Phase	1
Power Rating	25 W
Series	UP Series
Temperature Rating	140 deg F
Type	Canned Rotor
