Item Status:
Discontinued
Availability is limited to remaining stock.
INTERMOUNTAIN SALES (GRUNDFOS)
Up Series - Canned Rotor Circulator Pump - 7.71 GPM
Up Series - Canned Rotor Circulator Pump - 7.71 GPM
UP1518BUC7
Regular price
$503.67
Sale price
$503.67
Regular price
$523.00
Unit price
/
per
Shipping calculated at checkout.
How you'll get this item:
Available to order - Ships in 1 - 3 weeks
This is an estimated lead time. You'll get an email when it ships.
Stores Are Selected During Checkout.
Payment methods
COMPLEMENTARY PRODUCTS
MORE PRODUCT INFORMATION
DIMENSIONS
DIMENSIONS
|
WIDTH |
5.25 in |
|---|---|
|
HEIGHT |
7.75 in |
|
WEIGHT |
2.5 lb |
PRODUCT OVERVIEW
The Grundfos circulator pumps, Series UP are specifically designed for heating systems. The pumps are also suitable for circulation of hot domestic water and for circulation of liquid in cooling and air conditioning systems.
SPECIFICATIONS
|
Amperage Rating |
0.55 A |
|---|---|
|
Bearing Type |
Radial/Thrust |
|
Dimensions |
5-1/4 in W x 7-3/4 in H |
|
Flow Rate |
7.71 gpm |
|
Frequency Rating |
60 Hz |
|
Impeller Type |
Composite PES |
|
Maximum Head |
14.44 ft |
|
Maximum Pressure |
145 psi |
|
Phase |
1 |
|
Power Rating |
60 W |
|
Series |
UP Series |
|
Temperature Rating |
140 deg F |
|
Type |
Canned Rotor |
|
Voltage Rating |
115 V AC |

Up Series - Canned Rotor Circulator Pump - 7.71 GPM
$503.67
