GRUNDFOS

Versaflo Ups Canned Rotor Circulator Pump - 230 V AC - 1 Ph

Versaflo Ups Canned Rotor Circulator Pump - 230 V AC - 1 Ph

59896180

$245.50
$245.50 $254.00
Shipping calculated at checkout.

How you'll get this item:

  • Ach Direct Debit
  • Amazon
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

MORE PRODUCT INFORMATION

FEATURES

• Maintenance-free
• Low noise and low energy
• Complete range and wide range of accessories
• Stainless steel rotor can and bearing plate
• Corrosion-resistant impeller
• No additional motor protection is required
• Non-electronically controlled circulator pumps for domestic building with speed control
• Flange pipe connection
• Cast iron pump housing
• Small stator

DIMENSIONS

WIDTH

5.25 in

HEIGHT

6.5 in

WEIGHT

3.44 lb

DOCUMENTS & RESOURCES

Specification Sheet
User Manual
Product Brochure

PRODUCT OVERVIEW

UPS pumps constitute a complete range of 3-speed circulator pumps, available both in 50 and 60 Hz. The pumps can be used in both open and closed systems. UPS pumps are of the canned rotor type, i.e. pump and motor form an integral unit without a shaft seal and with only two gaskets for sealing. The bearings are lubricated by the pumped liquid.

SPECIFICATIONS

Amperage Rating

0.14 to 0.41 A

Bearing Type

Ceramic Radial/Carbon Thrust

Dimensions

5-1/4 in W x 6-1/2 in H

Frequency Rating

60 Hz

Impeller Type

Composite PES

Maximum Head

15.42 ft

Maximum Pressure

145 psi

Phase

1

Power Rating

92 W

Series

UPS

Temperature Rating

140 deg F

Type

Canned Rotor

Voltage Rating

230 V AC
